Impact Idler (T type)
JKC-T type
Application・Function
The hollow impact rubber is deformed to reduce the impact from the conveyed material at the hopper or chute opening, thereby reducing damage to the Belt or Idler.
Selection Guide
Use this product for heavier material (iron ore, agglomerate, limestone, etc.) with higher shock-absorbing effect than the M-type, and an apparent specific gravity of 1.0t per m3 or more, or in parts where the drop shock is relatively large. Selection at the same Trough Angle as the Carrier Idler is common. 35° and Trough Angles not shown are the products ordered.
Use Roller
Impact Roller KC-T type
Idler Model Number
Stand Model Number
Outline Dimension
Common dimension
(mm)
| B W | Model | H1 | H2 | m | A | n | B | D | l 1 | l 2 | U | t | a×b | F | BB |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 400 | JKC-3**-40 -T | 125 | 170 | 640 | 690 | 140 | 190 | 90 | 145 | 153 | 14.5 | 6 | 15×25 | L 50×50×6 | 6204ZZ |
| 450 | JKC-3**-45 -T | 125 | 170 | 690 | 740 | 140 | 190 | 90 | 165 | 173 | 14.5 | 6 | 15×25 | L 50×50×6 | 6204ZZ |
| 500 | JKC-3**-50 -T | 125 | 170 | 740 | 790 | 140 | 190 | 90 | 180 | 188 | 14.5 | 6 | 15×25 | L 50×50×6 | 6204ZZ |
| 600 | JKC-3**-60 -T | 140 | 185 | 840 | 890 | 150 | 200 | 90 | 210 | 218 | 14.5 | 6 | 15×25 | L 50×50×6 | 6204ZZ |
| 750 | JKC-3**-75 -T | 150 | 208 | 1040 | 1090 | 160 | 210 | 115 | 265 | 273 | 14.5 | 6 | 15×25 | L 65×65×6 | 6204ZZ |
| 900 | JKC-3**-90 -T | 150 | 208 | 1190 | 1240 | 160 | 210 | 115 | 315 | 323 | 14.5 | 6 | 15×25 | L 75×75×6 | 6204ZZ |
| 1050 | JKC-3**-105-T | 180 | 250 | 1340 | 1390 | 180 | 230 | 140 | 370 | 380 | 18.5 | 9 | 15×25 | L 75×75×6 | 6205ZZ |
| 1200 | JKC-3**-120-T | 180 | 250 | 1490 | 1540 | 180 | 230 | 140 | 420 | 430 | 18.5 | 9 | 15×25 | L 90×90×7 | 6205ZZ |
| 1400 | JKC-3**-140-T | 250 | 333 | 1730 | 1795 | 280 | 340 | 166 | 500 | 510 | 22.5 | 9 | 19×32 | L 100×100×10 | 6206ZZ |
| 1600 | JKC-3**-160-T | 250 | 333 | 1930 | 1995 | 280 | 340 | 166 | 580 | 590 | 22.5 | 9 | 19×32 | L 130×130×9 | 6206ZZ |
| 1800 | JKC-3**-180-T | 280 | 363 | 2220 | 2285 | 330 | 390 | 166 | 650 | 660 | 25.5 | 9 | 19×32 | L 130×130×9 | 6207ZZ |
| 2000 | JKC-3**-200-T | 280 | 363 | 2420 | 2485 | 330 | 390 | 166 | 730 | 740 | 25.5 | 9 | 19×32 | L 130×130×12 | 6207ZZ |
Various dimensions of by Trough Angle (α)
(mm)
| B W | Model | α=20° | α=30° | α=35° | α=45° | Weight（kg） | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| H3 | L | H3 | L | H3 | L | H3 | L | α=20° | α=30° | α=35° | α=45° | |||
| 400 | JKC-3**-40 -T | 223 | 460 | 246 | 422 | 256 | 400 | 276 | 388 | 14.0 | 14.1 | 14.2 | 14.6 | |
| 450 | JKC-3**-45 -T | 230 | 518 | 256 | 477 | 267 | 453 | 290 | 437 | 15.1 | 15.3 | 15.4 | 15.8 | |
| 500 | JKC-3**-50 -T | 235 | 561 | 263 | 518 | 276 | 492 | 301 | 473 | 16.3 | 16.5 | 16.5 | 17.0 | |
| 600 | JKC-3**-60 -T | 261 | 648 | 293 | 600 | 308 | 572 | 337 | 545 | 18.5 | 18.7 | 18.7 | 19.3 | |
| 750 | JKC-3**-75 -T | 301 | 797 | 344 | 756 | 363 | 721 | 399 | 677 | 24.5 | 25.1 | 25.2 | 26.1 | |
| 900 | JKC-3**-90 -T | 318 | 941 | 369 | 893 | 392 | 852 | 434 | 798 | 29.0 | 29.6 | 29.7 | 30.7 | |
| 1050 | JKC-3**-105-T | 381 | 1114 | 441 | 1053 | 467 | 1005 | 516 | 934 | 42.1 | 42.9 | 43.2 | 44.5 | |
| 1200 | JKC-3**-120-T | 398 | 1258 | 466 | 1189 | 495 | 1137 | 551 | 1054 | 50.3 | 51.2 | 51.5 | 52.7 | |
| 1400 | JKC-3**-140-T | 508 | 1490 | 589 | 1414 | 625 | 1351 | 691 | 1246 | 93.1 | 95.5 | 96.2 | 98.7 | |
| 1600 | JKC-3**-160-T | 536 | 1720 | 629 | 1632 | 671 | 1562 | 747 | 1439 | 109.0 | 111.5 | 112.3 | 114.9 | |
| 1800 | JKC-3**-180-T | 590 | 1922 | 694 | 1823 | 741 | 1747 | 834 | 1633 | 124.8 | 127.6 | 128.5 | 131.9 | |
| 2000 | JKC-3**-200-T | 617 | 2152 | 734 | 2042 | 787 | 1958 | 890 | 1826 | 149.9 | 152.9 | 153.9 | 157.4 | |
